LED poles are outdoor infrastructure products designed to support and secure LED luminaires, primarily used in urban roads, community streets, parks and squares, commercial pedestrian streets, industrial parks, and transportation hubs. As an essential component of the lighting system, LED poles not only provide stable support for the luminaires but also play a key role in enhancing spatial aesthetics, road landscape planning, and safety. Through scientifically determined height and structural arrangements, LED poles ensure the coverage and angle of light, delivering uniform illumination across roads or public spaces while minimizing light pollution and glare impact on the surrounding environment.
LED poles are typically constructed from high-strength steel, aluminum alloy, or composite materials and are treated with hot-dip galvanizing, anti-corrosion coatings, or powder coating to achieve excellent weather resistance and corrosion protection. This enables them to withstand long-term outdoor conditions, including wind, rain, sunlight, and temperature variations. The structural design of the poles is stable and reasonable, often adopting single-arm, double-arm, or multi-arm configurations to meet the requirements of different road widths, lighting levels, and landscape layouts. Modular and standardized designs make the installation, maintenance, and replacement of LED poles more convenient, improving construction efficiency and reducing operational costs.
In terms of functional expansion, modern LED poles not only serve as mounting structures for luminaires but can also integrate smart control modules, surveillance cameras, sensors, communication devices, and environmental monitoring equipment, achieving multifunctional integration for lighting, urban management, traffic monitoring, and public safety. When paired with intelligent control systems, LED poles can enable remote centralized management, scheduled on/off control, brightness adjustment, and energy consumption monitoring, optimizing streetlight operation strategies and enhancing energy efficiency.
Yangzhou Jinyuan Lamps Co., Ltd, which is affiliated with Jinshang Electric Group, is one of the professional provincial large-sized production, design, and engineering companies in the industry of road illumination in China. Since established from 2002, our products, which focus on street light poles, led street light, solar street light, light fixtures, etc., are highly appreciated by customers in domestic and overseas.
Established In
Site Area
Professional Technicians
Export Country
News Center
In outdoor lighting engineering, the structural stability and material durability of LED Poles are core indicators for measuring project quality. As a leading professional production, design, and engineering enterprise in the industry, Yangzhou Jinyuan Lamps Co., Ltd is always committed to providing high-standard road illumination solutions for the global market.
The main material of LED Poles is typically Q235 high-quality carbon structural steel. This material has excellent plasticity and welding performance, meeting the processing requirements of complex conical or polygonal shapes. When dealing with extreme climatic environments, aluminum alloy LED Poles are widely used in high-end landscape projects due to their lightweight and natural oxidation resistance.
| Parameter | Q235 High-Quality Steel | Aluminum Alloy (6063-T6) | Stainless Steel (304/316) |
| Mechanical Strength | Extremely high, suitable for ultra-high pole designs | Medium, suitable for under 12 meters | High, excellent tensile performance |
| Corrosion Resistance | Depends on hot-dip galvanization | Extremely strong, self-repairing oxide layer | Extremely strong, suitable for high salt mist areas |
| Wind Resistance | Excellent, wide range of wall thickness customization | Good, requires mechanical reinforcement | Excellent |
| Processing Flexibility | Extremely high, supports various irregular welding | Relatively high, mainly extrusion molding | Average, extremely high processing cost |
| Maintenance Cost | Low (regular coating inspection) | Extremely low (almost maintenance-free) | Extremely low |
To ensure that LED Poles do not rust during outdoor service, Yangzhou Jinyuan Lamps Co., Ltd strictly executes the hot-dip galvanization process in the production flow. The cleaned steel poles are immersed in molten zinc at approximately 450 degrees Celsius, forming a uniform and dense zinc-iron alloy layer on the steel surface. The thickness of this coating is usually required to reach over 85um, providing LED Poles with a rust-free lifespan of more than 20 years, maintaining structural integrity even in humid or acid rain-prone industrial areas.
On the basis of hot-dip galvanizing, LED Poles undergo electrostatic powder coating. We use high-performance polyester powder, which forms a hard protective film on the pole surface through high-temperature curing. This not only enhances the UV stability of LED Poles, preventing fading and peeling, but also provides a rich variety of color options to adapt to different urban landscape requirements.
The design of every LED Poles unit must undergo rigorous mechanical calculations. Based on the maximum instantaneous wind speed of the installation site (such as 160km/h or higher), the base diameter, top diameter, and steel plate wall thickness of the LED Poles are accurately determined. The engineering team at Yangzhou Jinyuan Lamps Co., Ltd performs stress simulations combined with the Effective Projected Area (EPA) of the luminaire to ensure the connection strength of the flange plate and anchor bolts can withstand long-term vibration and wind loads.
The lighting performance of LED Poles largely depends on the light source configuration of the lamp head. Since established in 2002, Yangzhou Jinyuan Lamps Co., Ltd has accumulated deep technical expertise in the fields of LED Poles, LED street lights, and solar street lights, ensuring that every lighting system achieves a balance of high luminous efficiency and low energy consumption.
High-performance LED Poles typically utilize high-power chips with ceramic packaging. These chips possess extremely low thermal resistance and excellent lumen maintenance rates. In practical applications, the luminous efficiency of a single chip can reach 150-180 lm/W, ensuring that LED Poles provide brighter road surface illumination under the same power consumption.
To minimize light spill and improve road uniformity, precision-designed secondary optical lenses are integrated into the LED Poles. Type II Lens is suitable for narrower roads, with the light spot elongated along the road direction. Type III Lens is suitable for conventional urban main roads, providing wider lateral coverage. Polarized Design reduces light pollution to residential areas on both sides of the road, precisely projecting light onto the target working surface.
| Technical Indicator | Industrial Standard | Yangzhou Jinyuan Lamps Co., Ltd Spec |
| System Luminous Efficacy | 120 - 140 lm/W | 150 - 165 lm/W |
| Color Rendering Index (CRI) | Ra is greater than or equal to 70 | Ra is greater than or equal to 75 (Optional Ra 80) |
| Color Temperature (CCT) | 3000K - 6500K | Supports full range customization |
| Lumen Depreciation | L70 is greater than 50,000h | L70 is greater than 100,000h |
| Input Voltage | AC 100-240V | AC 90-305V / DC 12-24V |
Heat dissipation is a critical factor determining the lifespan of LED Poles. The lamp head housing is usually made of high thermal conductivity die-cast aluminum, with an integrated fin design to increase the convection area. An effective thermal management system can control the chip junction temperature below 75 degrees Celsius, significantly extending the service life of internal electronic components in LED Poles and reducing replacement frequency.
During long-term outdoor operation, the stability of LED Poles depends not only on the mechanical structure but also on the complex internal electrical ecosystem. As a professional manufacturer with over twenty years of experience in road illumination, Yangzhou Jinyuan Lamps Co., Ltd follows high international B2B delivery standards in driver selection and circuit protection design.
The driver is known as the heart of the LED Poles. To ensure the light source maintains constant brightness under voltage fluctuations, we select drivers with a high power factor (PF is greater than 0.96) and extremely low total harmonic distortion (THD is less than 10%).
| Electrical Parameter | Industry Common Standard | Yangzhou Jinyuan Lamps Co., Ltd Standard |
| Power Factor (PF) | is greater than or equal to 0.90 | is greater than or equal to 0.96 at Full Load |
| Conversion Efficiency | 85 percent - 88 percent | 92 percent - 94.5 percent |
| Input Voltage Range | 100-240V AC | 90-305V AC (Global Wide Voltage) |
| Ripple Current | is less than 10 percent | is less than 5 percent (Reduced flickering) |
| Protection Grade | IP65 | IP67 (Full glue-filled waterproof process) |
Considering that LED Poles are usually installed in open outdoor environments, lightning strikes and grid surges are the primary causes of electrical failure. Yangzhou Jinyuan Lamps Co., Ltd equips every LED Poles system with a professional surge protection device capable of effectively absorbing instantaneous pulses up to 10kV or 20kV. This redundant design ensures that expensive LED modules and drivers remain safe even in extreme weather.
Modern LED Poles are no longer simple light emitters. By integrating 0-10V or DALI dimming interfaces, LED Poles can achieve time-segmented brightness control. For example, during late night hours when traffic is low, the power can be automatically reduced to 30 percent, saving significant operating electricity costs for municipal projects.
The design of LED Poles must be customized according to specific application scenarios. Yangzhou Jinyuan Lamps Co., Ltd, with its extensive engineering experience, provides optimized light distribution solutions for various environments.
On highways, the height of LED Poles is usually between 10 to 12 meters, with spacing between 30 to 35 meters. Due to high vehicle speeds, this places extremely high requirements on the color rendering and illumination uniformity of LED Poles. We reduce glare through precise light distribution angles, ensuring drivers have clear vision at night.
These areas require large-area, shadow-free lighting. High-mast LED Poles can carry multiple high-power lamp heads, covering areas with a radius of over 50 meters. This not only reduces the number of LED Poles installed but also lowers total maintenance costs.
Landscape LED Poles focus more on the aesthetic design of the exterior. Since 2002, Yangzhou Jinyuan Lamps Co., Ltd has been providing domestic and overseas customers with various elegantly shaped garden poles and landscape fixtures. These LED Poles serve as part of the city's landmarks while providing illumination.
| Application Scenario | Recommended Height (m) | Recommended Power (W) | Recommended CCT |
| Urban Main Road | 10 - 12 | 150 - 240 | 4000K - 5000K |
| Rural Road | 6 - 8 | 60 - 100 | 3000K - 4000K |
| Commercial Parking | 8 - 10 | 120 - 180 | 5000K - 5700K |
| Residential/Park | 3.5 - 5 | 30 - 60 | 2700K - 3500K |
High-quality LED Poles require standardized installation processes to guarantee a service life of several decades. As a provincial large-sized enterprise integrating design and engineering, Yangzhou Jinyuan Lamps Co., Ltd has summarized a set of standard installation procedures.
The stability of LED Poles originates from the foundation. The depth of the foundation pit must be determined based on the pole height and local soil structure. Anchor bolts must undergo hot-dip galvanizing for corrosion protection, and the horizontal error of the flange plate installation surface must be controlled within plus or minus 2mm during concrete pouring.
For the internal wiring of LED Poles, connections should be completed at the maintenance door. We recommend using IP68-rated junction boxes and fixing the circuit breaker in a position that is easy to maintain. All cable entries should be equipped with rubber grommets to prevent insulation damage caused by long-term vibration.
Although LED Poles produced by Yangzhou Jinyuan Lamps Co., Ltd have extremely high weather resistance, regular inspections are still necessary. Check the surface of LED Poles for paint peeling caused by accidental impacts. Regularly tighten flange nuts and lamp head fixing bolts. Wipe the glass surface of the lamp head to remove dust or bird droppings, maintaining optimal light output efficiency.
When selecting and deploying LED Poles projects, the accuracy of technical parameters and durability are key to decision-making. Yangzhou Jinyuan Lamps Co., Ltd, based on production experience since 2002, has compiled the most frequently asked technical questions from global B2B customers.
Production lead time depends on the order scale and level of customization. For standard specifications of LED Poles (such as 6-12m common conical poles), the production cycle is generally 15-20 working days. If special irregular designs or ultra-high pole projects are involved, the cycle may extend to 25-30 days due to additional stress analysis and mold adjustments.
Height selection directly affects road light coverage. Generally, for rural roads or sidewalks, 4-6 meter LED Poles are recommended. For urban secondary roads, 8-10 meter LED Poles are recommended. For main roads or highways, 10-12 meter or higher LED Poles are recommended. Yangzhou Jinyuan Lamps Co., Ltd can provide precise height suggestions based on Dialux lighting simulation data.
In coastal areas, chlorine ions in the air are highly corrosive to metal. Our LED Poles use hot-dip galvanizing on both internal and external surfaces, with zinc layer thickness complying with ISO 1461 standards (greater than or equal to 85um). Combined with fluorocarbon paint or polyester powder coating, they can pass salt spray tests of over 1000 hours.
Yes. Yangzhou Jinyuan Lamps Co., Ltd professionally produces matching solar LED Poles. These poles are designed with reinforced solar panel brackets and the pole center of gravity and wind resistance are adjusted based on the battery pack installation position.
No. We consider maintenance convenience when designing the lamp head connection of LED Poles. Standard hex keys or socket wrenches are usually sufficient for lamp head disassembly and angle adjustment. Furthermore, internal circuits often use quick-plug connectors for tool-free electrical connection.
| Pole Height (m) | Flange Size (mm) | Bolt Spec | Bolt Quantity |
| 6m | 280 x 280 x 14 | M18 x 600 | 4 |
| 8m | 330 x 330 x 16 | M20 x 800 | 4 |
| 10m | 350 x 350 x 18 | M22 x 1000 | 4 |
| 12m | 400 x 400 x 20 | M24 x 1200 | 6-8 |
For areas prone to tropical cyclones or strong winds, we increase the wall thickness of LED Poles (e.g., from 3mm to 4mm or 5mm) and enlarge the base diameter. Additionally, gussets are added at the connection between the flange plate and the pole body to disperse stress concentration.
Yes. To handle extreme rain and internal condensation, Yangzhou Jinyuan Lamps Co., Ltd configures IP67-rated constant current drivers for all high-performance LED Poles. This means the driver can function normally even if briefly submerged in water, ensuring system reliability.
We utilize secondary optical design to concentrate light on the road surface using asymmetrical lenses. For LED Poles, selecting lamp heads with Upward Light Output Ratio limits can effectively eliminate spill light. In Dialux simulations, we control the Threshold Increment within 10 percent to reduce glare for residents.
The length of LED Poles makes transportation challenging. We use multi-layer protective packaging: first wrapping the entire pole with bubble wrap or woven bags, with extra cardboard padding on critical parts like the flange and maintenance door. During container loading, wooden cradles are used to fix layers, preventing mutual friction during sea transit.
